Carbatec 317mm (12-1/2") Benchtop Thicknesser

Stock Code:
TH-B317P
Price:
$729.00 inc GST

Description

The Carbatec TH-B317P Benchtop Thicknesser features a powerful 1800W motor and can handle full width cuts in all types of timber. It will accept boards up to 150mm deep and 317mm wide and its two double sided replaceable blades will make effortless cuts becoming a valuable addition to your workshop. The slot located blades can be slightly offset from each other, in the case of a 'knick'.

This compact unit can cut thinner material up to 3mm per pass (wider boards need less cut depth per pass) and the handy depth cutting gauge make setting this up very simple. Safety features include full width anti kickback pawls and a standard fit No Volt Release (NVR) switch. The included dust chute can be mounted with Left or Right hand extraction and the inbuilt fan helps move wood shavings away from the cutterhead; although connection to a dust collector or vacuum is highly recommended. Folding in/out feed tables have a low friction coating and can be easily adjusted to reduce snipe. The optional stand (CT-BX-STAND) is made to perfectly match this machine and is pre-drilled to accept the supplied mounting bolts to enable a more permanent solution to your workshop.

Connection to high volume dust collection is necessary on this machine (as with most woodworking machines). Connection of a 4" dust hose (to the machines 2.25" dust port) is recommended. See optional adaptors & fitting method in the pictures to the left.

Features:

* 1800W Universal motor
* Folding infeed and outfeed tables
* Snipe reducing adjustment screws
* Low friction table
* Double Sided blades factory fitted
* Blade Knick offset ability
* Left or Right exit dust chute
* 2.25" dust port connection

Inclusions

- LH/RH Dust Chute
- Cutterhead Guard
- Blade Handling Tool
- Manual
- Setup and Maintenance Tools

* Specifications

Brand Carbatec
Motor 1800W (2.4HP) Universal, 10A plug
Cutterhead Straight Blade - 317mm Double Sided
Dust Port 2.25"
Infeed/Outfeed Roller Rubber
Maximum Cutting Width 317mm
Maximum Depth Of Cut 3mm
Minimum Stock Thickness 5mm
Maximum Stock Thickness 150mm
Table Material Low friction - pressed metal
Warranty Period 2 Years

An optional stand is available at extra cost - please see CT-BX-STAND.
