CrushGrind EASY - 150mm Shaft
Description
CrushGrind® is known for superior grinding performance. The ceramic construction ensures consistent and precise grinding, allowing users to adjust the coarseness of their spices or herbs with ease.
The ceramic used in CrushGrind® is extremely durable and resistant to wear and corrosion. This ensures that the grinder will maintain its performance over time.
CrushGrind offer a 25 year guarantee on the ceramic parts.
The CrushGrind® Easy mechanism is the newest designs from CrushGrind® that allows for a different method to secure the mechanism into the body and stopper (top) of the mill.
This mechanism uses 3 screws for the base and 2 for the top fixture. This eliminates the need for an internal groove on the inside of the body and top that receives the cantilever snap-fit when using the original CrushGrind® mechanisms.
The length of the mechanism is 150 mm, this mechanism makes a mill of about 175 mm tall, depending on your personal design.
CrushGrind EASY mechanism features:
* easy assembly inside wooden mills
* screws are used for mounting the mechanism and the stopper fixture
* well suited to small grinders that require a thin wall thickness and a flatter lid
* the low profile of the mechanism make it perfect for designs with very narrow mid sections
* filled by pulling the stopper fixture upwards (no need to unscrew any bolt)
* ceramic grinders make this suitable for grinding any spice, including rock salt.
Recommended Forstner style drill bits:
FSB-15MM
FSBT-28MM
FSBT-32MM
FSBT-45MM
We have included 4G x 3/8" self tapping screws - these were recommended by CrushGrind.
Suggested instructions are available below - click Download.
